主要用途
適用于中藥材的蒸、煮、燉、焯等加工，也可用于中藥的提取和濃縮以及食品、化工行業(yè)的釀造、消毒加工。

Main uses
Suitable to steam, boil, stew herb material, and it also can be used to extract, condense and disinfect in foods, chemical industries.

主要特點
易安裝、可傾斜、不污染產(chǎn)品、以蒸汽(電)為熱源、生產(chǎn)效率高，符合GMP要求。

Main technical characteristics
Easy installation. lilt, non-polluting products, steam (electricity) as heat source, high production efficiency, in line with GMP requirements.

主要技術參數(shù) Main technical parameter

型號 Type	全容積 total volume (m³)	工作壓力 working pressure (MPa)	工作溫度 working temperature (℃)	功耗 energy consumption (kg/h)	外形尺寸 dimension (mm)	總重量 weight (kg)
GT6J6-100	0.1	<0.3	<143	45~65	1500x706x784	150
GT6J6-200	0.2	<0.3	<143	60~75	1900x906x858	200
GT6J6-300	0.3	<0.3	<143	65~85	1950x1006x1010	260
GT6J6-500	0.5	<0.3	<143	85~100	2230x1206x1020	310
